In modern automation and control environments, operator interfaces demand both extreme flexibility and clear visual confirmation.
Visual Feedback directly on the Switch Surface:
A key advantage of this customizable CPS solution lies in how each key functions. Each individual key
integrates a display pushbutton, allowing programmable graphics, alphanumeric characters, and animated
sequences to be shown directly on the switch surface. By displaying functions, labels, and state updates
directly where users press, the keypad delivers immediate, dynamic visual feedback.
The 8-Key (2×4 Matrix) Customer-Programmable Switch (CPS) Keypad with Display (P/N: 24-6198) by Keetronics is a versatile human–machine interface designed to deliver intuitive, customizable user interaction.
- Multi-Display Support: Supports LCD, TFT, or OLED display technologies tailored to specific visual and graphic needs.
- RGB LED Backlighting: Enhances visibility and usability in both low-light and high-contrast operational environments.
- Customizable Visuals: Enables customized icons, graphics, colors, and display content to improve clarity and reduce errors.
- Compact 2×4 Form Factor: Combines an 8-key compact matrix with reliable performance and high adaptability.
Broad Communication Flexibility & Integration:
To ensure rapid and seamless compatibility with diverse system architectures, embedded platforms, and industrial control systems, the 8-key CPS keypad provides broad communication flexibility across major protocols:
- USB: Plug-and-play connectivity for computer-based control systems and operator consoles.
- RS-485: Reliable serial communication for robust industrial installations.
- I²C, UART, & SPI: Native protocol options for direct integration into embedded microcontrollers and custom host electronics.
"Designed and developed by Keetronics, this customizable CPS solution combines compact form factor, reliable performance, and high adaptability, making it ideal for applications requiring dynamic visual feedback and programmable control."
Built for Demanding Operational Environments:
The keypad is built with a durable mechanical design and a long key lifecycle, qualifying it as an industrial-grade input device capable of enduring rigorous routine usage. Users can program and adapt graphics, colors, and character indicators to match evolving system states, which significantly enhances operational clarity and prevents critical operator input errors.
Technical & Functional Overview:
Product Name: 8-Key Customer-Programmable Switches (CPS) with display Keypad
Product Code / P/N : 24-6198
Category: User Programmable Computer Keyboards
Grade: Industrial Grade
Switch Matrix: 8-Key (2×4 Matrix) Customer-Programmable Display Pushbuttons
Display Options: Supports LCD, TFT, or OLED Displays
Illumination: RGB LED Backlighting(optimised for low-light & high-contrast environments)
Display Content: Customizable icons, graphics, alphanumeric characters, and animated sequences
Supported Interfaces: USB, RS-485, I²C, UART, and SPI
Durability: Robust mechanical design with long lifecycle / long key life
Design & Origin: Designed and developed by Keetronics
Target Applications:
Engineered for high adaptability and dynamic visual interaction, the 8-Key CPS keypad is suited for:
- Industrial: Machinery interface panels, automated assembly control, and process supervision.
- Automation: Dynamic function switching and localized status monitoring.
- Medical: Critical diagnostic and operational equipment control panels needing intuitive clarity.
- Control Panels: Systems requiring programmable control, low operator error rates, and dynamic visual feedback.
