KIPL 26-6573
| Product Code | KIPL 26-6573 |
| Display Type | 5.8-Inch LTPS TFT LCD |
| Display Technology | Colour Active Matrix LTPS LCD |
| Resolution | 1920 × 1080 pixels, Full HD |
| Display Colours | 16.7M |
| Pixel Arrangement | RGB Vertical Stripe |
| Pixel Pitch | 0.066 × 0.066 mm |
| Display Mode | Transmissive / Normally Black |
| Viewing Angle | All directions |
| Luminance | 900 nits typical |
| Aspect Ratio | 16:9 |
| Display Interface | HDMI IN |
| Touch Technology | Capacitive Touch Panel |
| Touch Structure | G+G |
| Touch Resolution | 1920 × 1080 |
| Touch Controller | GT911 |
| Touch Interface | I²C |
| Touch Points | Five-point touch |
| Touch Logic Level | 3.3 V |
| Touch Interface via HDMI Board | Micro-USB or Molex-USB |
| Bonding Technology | Tape bonding between LCM and CTP |
| Active Display Area | 126.72(H) × 71.28(V) mm |
| Module Size | 144.56(H) × 87.40(V) × 21.26(D) mm |
| Weight | TBD |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -30°C to +80°C |
| Power Supply | 12 V DC via Micro USB |
| Module Current Consumption | 260 mA |
| Backlight | Not separately specified in the provided source |
| OSD Keypad | Included in product designation; detailed keypad specifications not provided in the source |
