7-Inch FHD Optically Bonded Display Module

The Keetronics 7-Inch FHD Optically Bonded Display Module is a compact, high-resolution display solution designed for demanding industrial, defence, and mission-critical HMI applications. The module combines a 7-inch TFT LCD, Full HD 1920 × 1080 resolution, optical bonding, EMI protection, and strengthened tempered glass in a rugged display assembly.

The display provides 1000 cd/m² brightness after optical bonding, a 1300:1 contrast ratio, and 16.7 million true 8-bit colours for clear and detailed visual output. Its 16:9 aspect ratio and 85° viewing angle in all directions provide consistent visibility across a wide viewing range.

The module incorporates optical bonding and a 1.8 mm tempered glass cover with ≥5H surface hardness. An EMI protective mesh with provision for 360° electrical grounding and 90% visibility is provided to support electromagnetic compatibility requirements. The design is specified to meet MIL-STD-461E/F and environmental testing as per JSS 55555-2012 or later.

With an operating temperature range of -30°C to +80°C, storage temperature range of -40°C to +90°C, and 10% to 90% non-condensing humidity tolerance, the display is designed for demanding environmental conditions.

The deliverable includes the 7-inch FHD display module, display cable assembly, and AD-board, providing an integrated solution for system-level display applications.
