Reliable human-machine interfaces are essential in demanding operational environments.
4 Keys Membrane Keypad:
Key Highlights:
Compact 4-key membrane keypad designed for mission-critical applications. Features long-life metal dome switches with consistent tactile response, reliable operation across wide temperature and humidity ranges, and secure adhesive mounting with controlled tolerances.
Production Information:
Built using high-quality metal dome technology delivering consistent tactile feedback with an operational life of up to 1 million actuations. Optimized for stable performance across wide temperature and humidity ranges,suitable for challenging battlefield and mission-critical environments. Designed for easy integration with controlled dimensional tolerances and well-defined adhesive mounting guidelines for secure installation and long-term reliability. Ideal for applications requiring compact, robust, and dependable user input interfaces.
Technical Specifications:
- Number of Keys: 4
- Degree of Protection: IP67 (testing to be conducted by customer)
- Dimensional Tolerance: ±0.2 mm
- LED Operating Voltage: 3.3 V / 5 V DC
- Contact Resistance: 10 Ohms
- Contact Bounce Time: 10 ms
- Activation Force: 280–350 grams
- Life Expectancy: 1 million operations (metal dome)
- Operating Temperature: -20°C to +70°C
- Humidity Resistance: 95% RH at 40°C for 48 hours
11 Keys Left Membrane Keypad:
Key Highlights:
11-key membrane keypad optimized for defense applications. Features metal dome switches with long operational life and tactile feedback, stable performance under wide temperature and humidity conditions, and secure adhesive mounting for reliable field deployment.
Production Information:
Features metal dome switch technology providing consistent tactile feedback with a service life of up to 1 million operations. Controlled actuation force ensures accurate key presses while minimizing accidental inputs. Designed to perform reliably under varying temperature and humidity conditions and supports secure adhesive mounting. Ideal for applications requiring a compact, durable, and dependable human–machine interface with proven performance and quality.
Technical Specifications:
- Number of Keys: 11
- Degree of Protection: IP rating (to be tested by customer)
- Dimensional Tolerance: ±0.2 mm
- LED Operating Voltage: 3.3 V / 5 V DC
- Contact Resistance: 10 Ohms
- Contact Bounce Time: 10 ms
- Activation Force: 300–380 grams
- Life Expectancy: 1 million operations (metal dome)
- Operating Temperature: -20°C to +40°C
- Humidity Resistance: 95% RH at 40°C for 48 hours
11 Keys Right Membrane Keypad:
Key Highlights:
11-key right-side membrane keypad for defense applications. Features metal dome switches with long operational life and tactile feedback, reliable operation in wide temperature and humidity conditions, and secure adhesive mounting in harsh environments.
Production Information:
MPN: KIPL 22-5824. Engineered to deliver dependable and precise user input for mission-critical defense and industrial systems. Developed by Keetronics, a manufacturer of advanced input devices with over 32+ years of industry experience, to meet the stringent requirements of battlefield andharsh-environment applications. Utilizes metal dome switch technology with consistent tactile response, a life expectancy of up to 1 million operations, and controlled actuation force to ensure accurate key presses while reducing operator fatigue. Supports secure adhesive mounting for durable, long-term field deployment.
Technical Specifications:
- Number of Keys: 11 (Right keypad configuration)
- Degree of Protection: IP67 (to be tested by customer)
- Dimensional Tolerance: ±0.2 mm
- LED Operating Voltage: 3.3 V / 5 V DC
- Contact Resistance: 10 Ohms
- Contact Bounce Time: 10 ms
- Activation Force: 300–380 grams
- Life Expectancy: 1 million operations (metal dome)
- Operating Temperature: -20°C to +60°C
- Humidity Resistance: 95% RH at 40°C for 48 hours
7 Keys Horizontal Membrane Keypad:
Key Highlights:
7-key horizontal membrane keypad designed for compact UI layouts. Features metal dome switches with long life and tactile feedback, reliable operation in wide temperature and humidity ranges, and secure adhesive mounting in harsh environments.
Production Information:
MPN: KIPL 22-5825. Engineered to provide precise and dependable user input for defense, industrial, and mission-critical systems. Designed and manufactured by Keetronics, with over three decades of experience, to meet the rigorous demands of battlefield and harsh-environment applications. Built using metal dome switch technology ensuring consistent tactile response with a life expectancy of up to 1 million operations. Controlled actuation force minimizes accidental key presses while maintaining user comfort. Supports secure adhesive mounting for long-term deployment in critical systems.
Technical Specifications:
- Number of Keys: 7 (Horizontal layout)
- Degree of Protection: IP rating (to be tested by customer)o
- Dimensional Tolerance: ±0.2 mm
- LED Operating Voltage: 3.3 V / 5 V DC
- Contact Resistance: 10 Ohms
- Contact Bounce Time: 10 ms
- Activation Force: 280–350 grams
- Life Expectancy: 1 million operations (metal dome)
- Operating Temperature: -20°C to +70°C
- Humidity Resistance: 95% RH at 40°C for 48 hours
7 Keys Vertical Membrane Keypad:
Key Highlights:
7-key vertical layout for space-efficient panel design. Features metal dome switches with long life and tactile response, reliable operation in wide temperature and humidity ranges, and suitability for defense and harsh industrial environments.
Production Information:
MPN: KIPL 22-5819. Engineered to deliver precise and dependable user input for defense, industrial, and mission-critical systems. Designed and manufactured by Keetronics, with over 32+ years of experience, to meet the stringent demands of battlefield and harsh-environment applications. Utilizes metal dome switch technology providing consistent tactile feedback and a service life of up to 1 million operations. Controlled actuation force helps prevent accidental key presses while ensuring comfortable and accurate operation. Supports secure adhesive mounting for long-term deployment in critical equipment.
Technical Specifications:
- Number of Keys: 7 (Vertical layout)
- Degree of Protection: IP rating (to be tested by customer)
- Dimensional Tolerance: ±0.2 mm
- LED Operating Voltage: 3.3 V / 5 V DC
- Contact Resistance: 10 Ohms
- Contact Bounce Time: 10 ms
- Activation Force: 280–350 grams
- Life Expectancy: 1 million operations (metal dome)o Operating Temperature: -20°C to +70°C
- Humidity Resistance: 95% RH at 40°C for 48 hours
Need a custom HMI architecture for harsh operating conditions? Contact Us
