18.5-Inch FHD Optically Bonded LCD Display

The Keetronics 18.5-Inch FHD Optically Bonded LCD Display is a rugged display module designed for demanding industrial, defense, and mission-critical HMI applications. It combines a high-resolution 1920 × 1080 Full HD LCD panel with optical bonding, strengthened AR cover glass, and EMI protection for reliable visual performance in challenging environments.

The display provides 16.7 million true 8-bit colors, a 16:9 aspect ratio, and 750 cd/m² luminance after optical bonding for clear and bright image reproduction. The 89° viewing angle in all directions supports wide-area visibility, while the LVDS interface provides display connectivity.

The display assembly incorporates 2.8 mm AR strengthened cover glass and optical bonding. An integrated EMI protective mesh provides 360° electrical connectivity and grounding, with approximately 85% visibility, and is designed to support EMI/EMC requirements referenced to MIL-STD-461E/F.

Designed for demanding environments, the module supports an operating temperature range of -20°C to +70°C and a storage temperature range of -30°C to +80°C. The design is specified to meet referenced requirements for dust, shock, and vibration, including JSS 55555, MIL-STD-810D, and MIL-STD-810E, subject to complete-unit testing and validation.

The assembled display solution is suitable for rugged HMI systems, industrial equipment, defense electronics, control consoles, and other applications requiring a high-brightness Full HD display with optical bonding and EMI protection.
