KIPL 26-6512
| Product Code | KIPL 26-6512 |
| Display Size | 27 Inch |
| Resolution | 1920 × 1080 pixels, Full HD |
| Display Type | TFT LCD |
| Display Colour | 16.7M, True 8 Bit |
| Aspect Ratio | 16:9 |
| Luminance | 1000 cd/m², after optical bonding |
| Contrast Ratio | 3000:1 |
| Response Time | 12 ms (Typical) |
| Viewing Angle | 89° / 89° / 89° / 89° |
| Interface | 2-Channel LVDS |
| Active Area | 597.6 (H) × 336.15 (V) mm |
| Pixel Pitch | 0.31125 × 0.31125 (H × V) |
| Cover Glass | 3 mm AG strengthened glass |
| Optical Bonding | Yes |
| EMI Mesh | EMI protective mesh with 360° electrical grounding provision and 85% visibility |
| Overall Dimensions | 644.20 × 388.40 × 14.00 mm (±0.6 mm) |
| LED Life | 50,000 hours |
| Operating Temperature | -20°C to +55°C |
| Storage Temperature | -30°C to +70°C |
| Humidity | 90% @ 60°C, non-condensing |
| EMI/EMC | EMI protective mesh with 360° electrical connectivity design to meet MIL-STD-461E/F* |
| Dust | Designed to meet JSS 55555, Test No. 14, Duration: 1 hour* |
| Shock | Designed to meet MIL-STD-810D* |
| Vibration | Designed to meet MIL-STD-810E* |
| Deliverables | Assembled 27-inch FHD LCD Display, 2 × Backlight Driver Boards, LVDS Cable, Backlight Cable |
