7-Inch Capacitive Touch LCD Display Module

The Keetronics 7-Inch Capacitive Touch LCD Display Module is a compact display solution designed for industrial HMI and embedded applications requiring clear visibility, responsive touch operation, and reliable performance across demanding environmental conditions.

The module features a 7-inch TFT LCD with 1024 × 600 pixel resolution, LED backlighting, 16.7 million colors, and 1000 cd/m² luminance for enhanced screen visibility. The display uses an LVDS interface and provides a typical response time of 30 ms.

For user interaction, the module integrates a Projected Capacitive (PCAP) touch screen with support for 10-point touch. The touch panel uses strengthened AG/AR/AF glass with ≥7H surface hardness, 3 mm glass thickness, and ≥85% transparency.

The LCD and capacitive touch screen are combined through optical bonding, helping create a compact integrated display assembly. With an operating temperature range of -30°C to +85°C and storage temperature range of -40°C to +90°C, the module is designed for applications requiring dependable operation across a wide temperature range.

The assembled module is suitable for industrial control panels, embedded HMI systems, operator interfaces, equipment displays, and other applications requiring an integrated touchscreen display solution.
